Model
|
Processor
|
Memory
|
Storage
|
Extension Interface
|
|---|---|---|---|---|
BV10/12/16 |
Support Intel® 6th to 14th Gen CPU | Support DDR4 ram，max to 32GB | Support 1*M.2 2280 for SSD support PCIe&SATA protocol | Up to 4*USB3.0，4*USB2.0 Up to 2 Lans； Optional DP/HDMI+HDMI/VGA dual display； |
E82 |
Support Intel 11th Tigerlake-U | 2*SO DIMM DDR4 | 1*MiniPCIe for Msata | Support 6*2.5G RJ45； 4*USB3.0, 2*USB2.0； 2*COM； |
BV10L/12L/16L |
Intel® 6th-14th CPU | 2xSO DIMM DDR4 supports up to64G | 1 x M.2 2280 for SSD （PCIE ） 1 x SATA HDD（2.5寸） | 1x 1000 MbpsRJ45 2 x USB3.0，2 x USB2.0，rear IO； 2 x USB3.0，2 x USB2.0，frontIO； 1× 3.5mm microphone jack, 1× 3.5mm headphone jack 1× Power LED, 1× HDD Activity LED |
BV212/216 |
Intel® 10th-14th CPU | 2xSO DIMM DDR4 supports up to64G | 1 x M.2 2280 for SSD （PCIE ） 1 x SATA HDD（2.5寸） | 1x 1000 MbpsRJ45 2 x USB3.0，2 x USB2.0，rear IO； 2 x USB3.0，2 x USB2.0，frontIO； 1× 3.5mm microphone jack, 1× 3.5mm headphone jack 1× Power LED, 1× HDD Activity LED |
BV220 |
6780A(8-core.7GHz) 6580A(8-core2.5GHz) 6640A(4-core2.6GHz) 6640M4-core2.2GHz） 6540M(4-core2.1GHz) | 2xSO DIMM DDR4 supports up to32G | 1 x M.2 2280 for SSD （PCIE ） 1 x SATA HDD（2.5寸） | 1x 1000 MbpsRJ45 2 x USB3.0，2 x USB2.0，rear IO； 2 x USB3.0，2 x USB2.0，frontIO； 1× 3.5mm microphone jack, 1× 3.5mm headphone jack 1× Power LED, 1× HDD Activity LED |
BV210 |
Phytium D2000, 8-core 2.3 GHz | 2xSO DIMM DDR4 supports up to32G | 1 x M.2 2280 for SSD （PCIE ） 1 x SATA HDD（2.5寸） | 1x 1000 MbpsRJ45 2 x USB3.0，2 x USB2.0，rear IO； 2 x USB3.0，2 x USB2.0，frontIO； 1× 3.5mm microphone jack, 1× 3.5mm headphone jack 1× Power LED, 1× HDD Activity LED |
BV103 |
Phytium D2000, 8-core 2.3 GHz | 2xSO DIMM DDR4 supports up to32G | 1 x M.2 2280 for SSD （PCIE ） 1 x SATA HDD（2.5寸） | 1x 1000 MbpsRJ45 2 x USB3.0，2 x USB2.0，rear IO； 4 x USB2.0，frontIO； 1× 3.5mm microphone jack, 1× 3.5mm headphone jack 1× Power LED, 1× HDD Activity LED |
B18 |
Support Intel® 10th/11th CPU | SO DIMM DDR4，Max to 64GB | Support 1*M.2 2280 for SSD | Up to 4*USB3.0，6*USB2.0 Up to 2*GbE Ethernet； Support DP+HDMI + HDMI ； |
V12 |
Support Intel ® Bay-trail processor | Onboard DDR3L memory，up to 4GB; | Support mSATA SSD; Support EMMC5.0 Flash; | Support VGA+HDMI display； Support 6*USB（5*USB2.0+1*USB3.0) |
BV2002 |
Intel® 10th-14th CPU | 2xUDIMM DDR4 supports up to64G | 1 x M.2 2280 for SSD （PCIE ） 4 x SATA 4 x SATA Gen3 Port | 1x 1000 MbpsRJ45 2 x USB3.0，4 x USB2.0，rear IO； 1x USB3.0，2 x USB2.0，frontIO； 1× 3.5mm microphone jack, 1× 3.5mm headphone jack 1× Power LED, 1× HDD Activity LED |
B20 |
Intel skylake-U/kabylake-U CPU | Support 2*DDR4 memory，max to 32GB | Support 1*Msata； Support 1*2.5" HDD； Support 1*M.2 2280 SSD； | Up to 3*USB3.0，3*USB2.0， Up to 2*Gigabit Ethernet； Support VGA+HDMI display port; |
.png)
BV810 |
6780A(8-core.7GHz) 6580A(8-core2.5GHz) 6640A(4-core2.6GHz) 6640M4-core2.2GHz） 6540M(4-core2.1GHz) | 2xUDIMM DDR4 supports up to32G | 1 x M.2 2280 for SSD （PCIE ） 1 x SATA HDD（2.5-inch） | 1x 1000 MbpsRJ45 2 x USB3.0，2 x USB2.0，rear IO； 4 x USB2.0，frontIO； 1× 3.5mm microphone jack, 1× 3.5mm headphone jack 1× Power LED, 1× HDD Activity LED |
E30 |
Support Intel® Apollo Lake | Support DDR3L-1866MHz, max to 4GB | Support mSATA SSD、EMMC5.0 Flash | Support HDMI，4K display up to 10*USB（2 x USB 3.0+8 x USB 2.0） |
V20 |
Support Intel® Bay-trail processor | 1* DDR3L SO-DIMM，max to 8GB | Support mSATA & EMMC5.0 Flash ； | Up to 2*GbE； Support 6*USB（5*USB2.0+1*USB3.0); Support HDMI+VGA ; |
P238W6-12/16 |
Intel® 10th-14th CPU | 2xSO DIMM DDR4 supports up to32G | 1 x M.2 2280 for SSD （PCIE ） 1 x SATA HDD（2.5-inch） | 1x 1000 MbpsRJ45 4*USB3.0，2*USB2.0 1× 3.5mm microphone jack, 1× 3.5mm headphone jack 1× Power LED, 1× HDD Activity LED |
E20 |
Support Intel ® 6/7th U series processor； | Support dual-chanel DDR3，max to 32GB | Support 2.5“ HDD & mSATA SSD &M.2(2242/2280) SSD | Up to 6*USB（3 x USB 3.0+2 x USB 2.0+1 x Type C）； 6*COM（4xRS232+2xRS485） |
EB16 |
Support Intel 12th/13th CPU | 2*SO DIMM DDR4 | Support 1*M.2 2280 for SSD | Up to 4*USB3.0，4*USB2.0 Up to 2*GbE Ethernet； Optional DP/HDMI+HDMI/VGA； |
.png)
BV820 |
Phytium D2000, 8-core 2.3 GHz | 2xUDIMM DDR4 supports up to32G | 1 x M.2 2280 for SSD （PCIE ） 1 x SATA Gen3 Port | 1x 1000 MbpsRJ45 2 x USB3.0，4 x USB2.0，rear IO； 1x USB3.0，2 x USB2.0，frontIO； 1× 3.5mm microphone jack, 1× 3.5mm headphone jack 1× Power LED, 1× HDD Activity LED |
B50 |
Support Intel® 6th/7th/8th/9th CPU | Support DDR4 Memory，up to 32GB | Support 1*full-size Mini PCIe for mSATA | Up to 2*Gigabit Ethernet； Up to 4*USB3.0，4*USB2.0 |
B16 |
Support Intel® Skylake-H /Kabylake -H | Support dual-chanel DDR4，max to 64GB | 1 x full-size Mini-PCIe for mSATA | Support DP+HDMI+VGA display Support 4*COM，1*LPT |
